Icom 7300 Com Port and USB Audio CODEC Fix

Hey guys! I’m at Devils Tower and operating Parks on the Air (POTA). My IC-7300 hit a SNAFU, so I wanted to write about it. The com port and USB Audio CODEC went missing in Device Manger. The next time this happens I can look back and see what the fix was. I had this trouble before and didn’t write it down. Here’s my USB Audio CODEC fix and it fixed my com port too.

Of course this will work with any Icom radio using the USB driver download.

Getting the most out of your radio?

Please join our growing Icom 7300/7610 community.

I agree to have my personal information transfered to MailChimp ( more information )

Receive e-mail notifications of new articles. I will never give away, trade or sell your email address. You can unsubscribe at any time.

The Problem

I am using Windows 10. So basically the trouble started when I was using Log4OM, WSJT-X and Gridtracker. I minimized those while talking to some Hams on the Cormac CQ 100 program. While chatting, WSJT-X showed an error “USB Audio not connected”, “Soundcard input error” or something of that nature. I closed it and the logging program as well as Gridtracker. Later when I went back to open everything no joy. After opening Device manager I saw my Com port was missing as well as the Audio CODEC. That was the problem. It was not recognizing my Com port or Audio CODEC.

I tried everything including reinstalling the USB driver from Icom. Still nothing and in Device Manager the device (Com port and Audio CODEC) was showing up under “USB Serial bus controllers” and it had a warning icon attached to it. It was not working.

Prelude

I uninstalled the faulty device (remember, it had a warning symbol next to it) from Device Manager and then disconnected the USB cable. After which I went to add/remove programs and uninstalled the Silicon Driver Program. Just search for “silicon” in the search field of add/remove programs and you’ll find it. I restarted the computer for good luck, hi hi.

Intermission

I was just getting ready to activate Devils Tower for Parks on the Air (POTA) and didn’t want to wait. I started with phone (USB) on 20 Meters. So my logging programs would work I had the CI-V cable and I used it for rig control. Handy little cable. I made a bunch of phone contacts on 20 Meters. Yeah buddy!

Radio: IC-7300, Mic: SM-50, Antenna: Hi-Q Mobile 5/80 and 100 watts.

USB Audio CODEC Fix

I tried everything including reinstalling the USB driver from Icom. Still nothing and in Device Manager the device (Com port and Audio CODEC) was showing up under “USB Serial bus controllers” and it had a warning icon attached to it. It was not working.

Eventually I went to the Microsoft website and downloaded the “Windows 10 upgrade 9252” file. It’s under the Windows 10 May 2021 update heading. Click the “Update Now” button for the file. When I ran it Windows started a download of the update. It took a while, but eventually finished and told me I needed to restart the computer, which I did. On rebooting it did an upgrade and restarted a couple of times, but after about ten minutes or so, the Windows login screen came up.

https://www.microsoft.com/en-gb/software-download/windows10

Finished

I was able to reinstall the Icom USB driver and then connect the cable to my IC-7300. In device manager, eveything was as it should be. I was back up and running WSJT-X. I made another 20 or so contacts on FT-8 and now I can move onto PSK31.

Thank You

Lesson learned: Write this stuff down. The stroke I had messed with my memory and I am getting older.

Thanks and I hope this helps someone else. If you have had a similar problem, how did you fix it?

Thank you for subscribing to this website. You can also follow me and my travels on TwitterFacebookInstagram and YouTube. See my spots on POTA.

73,
Rich, K0PIR

Sources:

Windows 10 May 2021 Update

Icom USB Driver Download

QSONet and Cormac CQ100

NOTE: Do this fix at your own risk. I don’t see how you could lose.

Some photos from Devils Tower. Look for my spots on the POTA website.
